Bosch ME17.8.10 ECU Technical Guide

The guide does not provide values or percentages on how much calibration maps should be modified.

This 30-page technical reference guide is dedicated to the Bosch ME17.8.10 ECU family and can be used as a reference for all ME17.8.10 CF Moto motorcycles and ATV (CF Moto, Segway, Goes, Linhai).

It provides detailed information about ECU architecture, identification, reading and writing solutions, ecu strategies, map functions (related to the OldSkullTuning XDF definition) and relationships between maps, helping users better understand how the different functions interact inside the ECU.

Main topics covered in the Bosch ME17.8.10 ECU Technical Guide:

• ECU overview, identification and supported applications
• ECU reading and writing tools
• ECU operating strategies and calibration structure
• Ignition strategy and ignition advance maps
• Lambda control and component protection strategies
• Airflow, throttle and cylinder filling calculations
• Torque calculation and torque limitation strategies
• Torque monitoring
• Ride by wire maps
• Exhaust temperature calculation and thermal protection
• RPM, speed and throttle limitation strategies
• Map functions and interaction between related maps
• Map relationship quick reference
